Corner Cube Prisms
Corner Cube Prism has the property that any incident beam will be reflected parallel to itself, regardless of the incident angle. These prisms are ideal where precision alignment is difficult or time-consuming.

Material:                         BK7 grade A optical glass, UV grade fused silica etc.

Dimension Tolerance:     +/-0.05mm

Surface Accuracy:         λ/8 @632.8nm

Wavefront Distortion:   λ/4 @632.8nm

Beam Deviation:          <2 arc sec

Angle Tolerance:         <5 arc sec

Surface Quality:            20-10

Clear Aperture:             > 90%

Bevel:                           0.2mm×45°

Coating:                       user-defined
